Overview
This IP is a fully integrated system-on-chip radio transceiver targeting Smart Grid applications. The performance is tailored for extremely low power operation to be used in sensor monitoring networks and remote control for wireless networks. Transmitter output power ranges from -8 to +15 dBm, while receiver sensitivity is -110 dBm at 25kbps data rate.
Additional peripherals such as ADC, SPI, I2C, UART, I2S and timers are all included on the same chip, resulting in a compact system solution.This is ideal for portable applications in frequency ranges 863-928 MHz , in particular those needing long battery life and/or signal processing, such as AMR, WSN and medical.
Provider
T2M GmbH is the leading Global Technology Company supplying state of the art complex semiconductor connectivity IPs and KGDs, enabling the creation of complex connected devices for Mobile, IoT and Wearable markets.
T2M's unique SoC White Box IPs are the design database of mass production RF connectivity chips supporting standards including Wifi, BT, BLE, Zigbee, NFC, LTE, GSM, GNS. They are available in source code as well as KGD for SIP / modules.
With offices in USA, Europe, China, Taiwan, South Korea, Japan, Singapore and India, T2M’s highly experienced team provides local support, accelerating product development and Time 2 Market.
