HCLTech Offers IP Process Monitor IP (hcl_procmon_t40_v2) consists of three ring oscillators namely RVT Ring Oscillator, Thick ox…
Overview
HCLTech Offers IP Process Monitor IP (hcl_procmon_t40_v2) consists of three ring oscillators namely RVT Ring Oscillator, Thick oxide Ring Oscillator, & HVT Ring Oscillators. In RVT Ring Oscillator the MOS is of regular threshold Voltage, in thick oxide Ring Oscillator MOS of is of thick oxide & in HVT ring oscillator the MOS is of high threshold voltage. The frequency of specific ring oscillators dictates the process of the device, indicating whether it operates under a fast, typical, or slow process. In this IP block Resistor and Capacitor Segments have been added for measuring the process of the Resistor and the Capacitor.
Key features
- Monitors process of Regular threshold voltage (RVT), Thick oxide (TD), High threshold voltage (HVT) devices. It monitors the process of Resistor and Capacitor as well.
- Digital supply Voltage range is from 0.9V to 1.1V, typical voltage is 1V.
- Temperature range is from -40°C to 125°C, typical temperature is 27°C.
- The input clock frequency of 500 KHz originates from the RC oscillator, which is utilized for the counter .
- The Layout area is 42437.901 sq um.
- Technology Node TSMC40nm, 1p7m.
Block Diagram
HCLTech_promon_t40_v2 block diagram
Applications
- The Process Monitor block determines the process of Regular threshold voltage (RVT), Thick oxide (TD), High threshold voltage (HVT) devices i.e. either Fast, Typical or Slow process.
- It also determines the process of Resistor and Capacitor.
Silicon Options
| Foundry | Node | Process | Maturity |
|---|---|---|---|
| TSMC | 40nm | G | — |
