Vendor: RFIC Solutions, Inc. Category: RF Front End

RF SPDT Switch from 2-44 GHz used in TDD (Time Division Duplexing) mode for switching between TX and RX path with low loss, broadband and high isolation

RFSW03C RF SPDT Switch is used in TDD (Time Division Duplexing) mode for switching between TX and RX path with low loss, broadban…

Contact Provider Request Datasheet

Overview

RFSW03C RF SPDT Switch is used in TDD (Time Division Duplexing) mode for switching between TX and RX path with low loss, broadband and high isolation. This RF switch is Reflective type and the design incorporates series-shunt circuit elements with the locations optimized to achieve outstanding broadband performance in 2 - 44 GHz. The combination of broadband performance along with very fast switching and excellent settling time make this device ideal for many applications including Test & Measurement, EW and broadband communication systems. This switch is designed using the 0.1um GaAs pHEMT process. Results shown in datasheet with all parasitics and coupling effects at desired frequency.

Key features

  • Broad band frequency Range: 2-44GHz
  • Low Insertion Loss: 2.1dB
  • High Isolation: 45dB
  • Fast Switching Speed
  • Reflective Configuration
  • Ultra Low DC Power Consumption
  • Die size: 1.15 mm x 1.85 mm

Block Diagram

RFSW03C block diagram

Benefits

  • Low Insertion Loss
  • High Isolation
  • Fast Switching Speed
  • Reflective Configuration
  • Ultra Low DC Power Consumption
  • Good input and output VSWR’s
  • Low cost
  • IP can be ported to 65nm Si/CMOS node

Applications

  • 5G mobile system
  • RF Antenna
  • Test & Measurement
  • Aircrafts and Radar systems
  • EW and broadband communication systems
  • Space Based communication system

What’s Included?

  • Schematic and Net List
  • Abstract Model (.lib file)
  • Layout View (Optional)
  • Behavioral Model (Circuit & EM Simulation)
  • Extracted View (Optional)
  • GDSII
  • DRC, LVS, Antenna report
  • Test bench with saved configuration (Optional)
  • Documentation

Specifications

Identity

Part Number
RFSW03C
Vendor
RFIC Solutions, Inc.
Type
Silicon IP

Provider

RFIC Solutions, Inc.
HQ: United States
RFIC Solutions, Inc. is a fabless semiconductor company focused exclusively on wireless Solutions. RFIC Solutions Inc. offer RFIC, Analog, Digital & Mixed signal IC design services. RF Modules/Board design Services & FPGA design & development services are also provided. RFIC Solutions designs highly integrated system on chip (SOC) and system on a package (SOP); custom ICs, MIC for any wireless systems including cellular, Wi-Fi, WLAN, WiMax and UWB systems. We have designed more than 600 RFICs covering frequency range from 0.01 to 100 GHz. We have expertise in designing LNA, PA, VCO, PLL, complete Transceiver IC, ADC, Mixers, SPDT/DPDT switches at high frequency, 6Bit Attenuator, Complex Band Pass Filter, Op-Amp, PGA, VGA, Prescaler for applications ranging from DC to 40 GHz. These designs are available on SiGe BiCMOS, Si CMOS InGaP, RFCMOS, GaAs pHEMT, technologies provided by our foundry partners Tower Jazz semiconductor, GCS, TSMC, Triquint, Globalfoundries, IBM, Win semiconductors.
