Verification IP for AMBA ATB

Synopsys Verification IP (VIP) for Arm® AMBA® ATB™ provides a comprehensive set of protocol, methodology, verification, and produ…

Contact Provider Request Datasheet
Verification IP View all specifications

Overview

Synopsys Verification IP (VIP) for Arm® AMBA® ATB™ provides a comprehensive set of protocol, methodology, verification, and productivity features, enabling users to achieve accelerated verification closure of Arm AMBA ATB based designs.

Key features

  • Trace Data Transfer (Valid, ready signaling)
  • Narrow Trace Data Transfer (Data Valid Bytes signaling)
  • Flow Control (Valid, ready signaling)
  • Flush Request Response (Flush Valid, Ready signaling with Data transfer)
  • Synchronization Request capture and pass to Trace Source (i.e. Sequence layer)
  • Secondary Random Response for Trace Data Transfer
  • Secondary Random Flush Request Generation
  • Secondary Random Synchronization Request Generation
  • Secondary Memory (for Trace Data capture)

Block Diagram

Verification IP for AMBA ATB block diagram

Benefits

  • Native SystemVerilog/Verilog with UVM
  • Includes primary, secondary, monitor
  • Runs natively on all major simulators
  • Built-in UVM sequence library
  • Verdi® protocol aware debug

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.

Specifications

Identity

Part Number
Verification IP for AMBA ATB
Vendor
Synopsys, Inc.
Type
Verification IP

Provider

Synopsys, Inc.
HQ: USA
Synopsys is a leading provider of high-quality, silicon-proven semiconductor IP solutions for SoC designs. The broad Synopsys IP portfolio includes logic libraries, embedded memories, analog IP, wired and wireless interface IP, security IP, embedded processors and subsystems. To accelerate IP integration, software development, and silicon bring-up, Synopsys’ IP Accelerated initiative provides architecture design expertise, pre-verified and customizable IP subsystems, hardening, and signal/power integrity analysis. Synopsys' extensive investment in IP quality, comprehensive technical support and robust IP development methodology enables designers to reduce integration risk and accelerate time-to-market.
