PTP/gPTP Verification IP

The PTP/gPTP Verification IP provides an effective & efficient way to verify the components interfacing with PTP/gPTP interface of an IP or SoC. The PTP VIP is fully compliant with IEEE 1588-2008 specification and gPTP VIP is fully compliant with IEEE 802.1AS-2011 specification. This VIP is lightweight with an easy plug-and-play interface so that there is no hit on the design cycle time.

• Provides Ethernet fully compliant to 802.3-2018 supporting all media independent interfaces for (1/10/25/40/50/100/200/400/800 G)
• Provides PTP as per IEEE 1588-2008 specification
  • Supports BMCA
  • Supports PTP Delay Request Mechanism (Announce-sync-FollowUp-DelayReq-DelayResp)
  • Supports PTP Peer Delay Mechanism (PdelayReq – PdelayResp - PdelayRespFollowUp)
  • Supports Local Clock generation with user configurable start for timestamp generation
  • Supports Master-Slave and slave only port state machines capable with support for all message timers
  • Supports basic Management Messages with user control from test/sequence
  • Supports one step and two step clock timestamping
• Provides gPTP as per IEEE 802.1AS-2011 specification
  • Supports time-aware end stations
  • Supports all types of Messages (Announce-sync-FollowUp-Pdelay Req – PdelayResp – PdelayRespFollowUp-signalling)
  • Supports Peer Delay Mechanism and Mean Propagation delay calculation using peer delay messages
  • Supports timestamping at the gPTP level with information for the local clock
  • Supports BMCA(priority vector calculation and comparison) with determination of selectedRole
  • Supports Local Clock generation with user configurable start for timestamp generation
• Supports clock data recovery(CDR).
• Supports test pattern generation and checking.
• Supports Management data Input/output registers.
• Supports full-duplex operation.
• Callback support in all Layers to provide user control.
• Rich set of configuration and parameters.
• Supports Dynamic as well as Static Error Injection scenarios.
• Built-in Coverage analysis.
• Graphical analyzer to show transactions for easy debugging.

• Available in native System Verilog (UVM/OVM/ VMM) and Verilog
• Unique development methodology to ensure the highest levels of quality
• Availability of Compliance & Regression Test Suites
• 24X5 customer support
• Unique and customizable licensing models
• Exhaustive set of assertions and coverage points with connectivity examples for all the components
• Consistency of interface, installation, operation, and documentation across all our VIPs
• Provide complete solutions and easy integration in IP and SoC environment

• Deliverables PTP/gPTP BFM's for
  • PTP layer
  • gPTP layer
  • MAC layer (optional)
• PTP/gPTP monitors and scoreboard
• Mac monitors and scoreboard (optional)
• Test environment and Test Suite-
  • Basic and Directed Protocol Tests
  • Random Tests
  • Error Scenario Tests
  • Assertions & Cover Point Tests
  • User Test Suite
• Integration Guide, User Manual, and Release Note
• GUI analyzer to view simulation packet Flow
