MIPI CSI-2 TX Controller

CSI-2 transmitter controller for application processor The Transmitter (TX) Controller IP for MIPI® Camera Serial Interface 2 (CS…

Contact Provider Request Datasheet

Overview

CSI-2 transmitter controller for application processor

The  Transmitter (TX) Controller IP for MIPI® Camera Serial Interface 2 (CSI-2sm) is responsible for handling image sensor data in multiple RGB, YUV, and RAW formats, and user-defined data formats, while converting these into CSI-2-compliant packets for transmission over a D-PHYsm interface via the PPI interface.

The TX Controller IP for CSI-2 can handle up to four independent pixel streams and can perform Virtual Channel and Data Type interleaving before transmission four PPI data lanes.

Key features

  • Standards Compliance. CSI-2 v2.1, with 8-bit PPI data width and links with 1, 2, or 4 data lanes
  • Provides up to 4 Independent Stream Output Interfaces, allowing a highly configurable range of options, including multiple pixel modes, various buffering modes, packed data mode, Data Type selection, and Virtual Channel or Data Type interleaving

Block Diagram

MIPI CSI-2 TX Controller block diagram

Applications

  • Automotive,
  • Communications,
  • Consumer Electronics,
  • Data Processing,
  • Industrial and Medical,
  • Military/Civil Aerospace,
  • Others

What’s Included?

  • Unencrypted, synthesizable Verilog HDL
  • Cadence Genus™ Synthesis Solution scripts
  • Documentation—Integration and User Guide, Release Notes
  • Demonstration testbench with integrated Cadence Verification IP (VIP)
  • Software Driver
