Vendor: Dolphin Semiconductor Category: DC/DC Converter

Audio-Grade DC/DC Buck Converter in GF 22FDX

DCDC-ADG-1.62-5.5-0.5-3.3-A01-G22FDX+_GF_22_FDX+ is an Audio Grade DC/DC Buck Converter in GF 22FDX+ aimed at supplying battery-p…

Contact Provider Request Datasheet
GlobalFoundries 22nm FDX View all specifications

Overview

DCDC-ADG-1.62-5.5-0.5-3.3-A01-G22FDX+_GF_22_FDX+ is an Audio Grade DC/DC Buck Converter in GF 22FDX+ aimed at supplying battery-powered audio IPs.

PARAMETERS CONDITION

Minimum value

Typical value

Maximum value

Input Voltage

 - 1.62 V   5.5 V

Output Voltage

 - 0.55 V   3.3 V

Output current configuration

 - - 100 mA;200 mA;50 mA -

Quiescent current typical value

 385 nA -   -

Key features

  • Quiescent current (typ): 385 nA
  • Shutdown current (typ): 165 nA
  • Peak efficiency (typ):
    • 3.3 V to 1.8 V: up to 90%
    • 3.3 V to 0.8 V: up to 82%
  • Efficiency at 0.1% of Imax=200mA (typ): 82%
  • Efficiency at 10 µA (typ): 70%
  • Output voltage DC accuracy: 3%

Block Diagram

DCDC-ADG-1.62-5.5-0.5-3.3-A01-G22FDX+ block diagram

Benefits

  • Supply noise-sensitive audio blocks via an ultrasonic mode: 25 kHz switching frequency clamping
  • High efficiency, PFM modulation
  • Programmable output voltage
  • Output current limiter
  • Configurable output stage for optimized area adapted to load current
  • Embedded power pads with ESD protections and HV-tolerant
  • Embedded voltage reference
  • Embedded soft-start solution
  • Embedded Regulation OK output
  • Active/Shutdown modes set by EN and High impedance output mode set
  • by HIZ input (for test purpose only)

Applications

  • Bluetooth
  • Cellular IoT
  • GNSS
  • Hearing aids
  • NB-IoT
  • Smart Headset
  • Smart Speaker
  • TWS Earpods
  • ULP MCU
  • Voice-controlled devices

Silicon Options

Foundry Node Process Maturity
GlobalFoundries 22nm FDX —

Specifications

Identity

Part Number
DCDC-ADG-1.62-5.5-0.5-3.3-A01-G22FDX+
Vendor
Dolphin Semiconductor
Type
Silicon IP

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.

Provider

Dolphin Semiconductor
HQ: France
