Vendor: Cadence Design Systems, Inc. Category: DSP Core

Vision DSP built using 128-bit SIMD and offering up to 0.4 TOPS of performance

Built using 1024-bit SIMD and offering up to 3.84TOPS of performance The Cadence® Tensilica® Vision Q8 DSP delivers up to 3.84 te…

Contact Provider Request Datasheet

Overview

Latest Energy Vision DSP targeting low-end Vision/Radar and AI SOC market

The Cadence Tensilica Vision 110 DSP is the latest addition to the Vision DSP family. The smallest Vision DSP targets lower power, always-on applications offering one-third the power and area compared to the 512-bit SIMD Vision 130 DSP, while offering an easy software transition from Vision 110 via the N way programming model, and previous generation Vision P1 DSP. Vision 110 DSP also offers the flexibility to configure without various features to reduce area and the data RAM.

Key features

Cadence, through its Tensilica processor IP, brings together best-in-class products and services from industry leaders to help you accelerate the development of your SoC designs while meeting your demanding power and performance requirements. Browse the list of Tensilica processor IP service partners below.

  • 256/128b Load/Store capabilities
  • 128 8-bit MAC
  • 8/16/32-bit fixed-point processing
  • Single-precision (FP32) and half-precision (FP16) floating-point processing
  • Integrated 3D iDMA
  • User-defined instructions support
  • Built on LX8 Xtensa processor offering best energy efficiency
  • ISO 26262 ready for automotive market

Block Diagram

Click to open fullscreen

Benefits

Area and Power Optimized

128-bit SIMD with lowest area and power among the Vision DSPs and lower power compared to host CPU and GPU

Vision/Image Processing

Instructions set optimized for computer vision and image processing applications

High Performance

> 0.256TOPS AI performance for object detection, image classification, Image segmentation

Applications

  • Automotive,
  • Communications,
  • Consumer Electronics,
  • Data Processing,
  • Industrial and Medical,
  • Military/Civil Aerospace,
  • Others

Specifications

Identity

Part Number
Vision 110 DSP
Vendor
Cadence Design Systems, Inc.
Type
Silicon IP

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.

Provider

Cadence Design Systems, Inc.
HQ: USA
If you want to achieve silicon success, let Cadence help you choose the right IP solution and capture its full value in your SoC design. Cadence® IP solutions offer the combined advantages of a high-quality portfolio, an open platform, a modern IP factory approach to quality, and a strong ecosystem. Now you can tackle IP-to-SoC development in a system context, focus your internal effort on differentiation, and leverage multi-function cores to do more, faster. The Cadence IP Portfolio includes silicon-proven Tensilica® IP cores, analog PHY interfaces, standards-based IP cores, verification IP cores, and other solutions as well as customization services for current and emerging industry standards. The Cadence IP Factory provides you with an automated approach to the customization, delivery, and verification of SoC IP. As a result, you can spend more time on differentiation, with the assurance that you'll meet your performance, power, and area requirements. Choosing Cadence IP enables you to design with confidence because you have more freedom to innovate your SoCs with less risk and faster time to market.
