Vendor: Synopsys, Inc. Category: VESA DSC

VESA VDCM 1.1 Encoder

The VESA Display Stream Compression (DSC) Encoder and Decoder IP provides a video compression solution for up to 10K ultra-high-d…

Contact Provider Request Datasheet

Overview

The VESA Display Stream Compression (DSC) Encoder and Decoder IP provides a video compression solution for up to 10K ultra-high-definition displays over HDMI 2.1, MIPI DSI, and VESA DisplayPort links. The IP enables designers to incorporate visually lossless data compression between the SoC and display to maximize video bandwidth and optimize power, and area for mobile, automotive, and AR/VR applications. The VESA DSC IP, consisting of encoder and decoder, is compliant with the latest VESA DSC 1.2a and 1.1 specifications.

The MIPI DSI Host Controller IP with VESA DSC encoder together with the MIPI D-PHY and C-PHY/D-PHY IP provide a complete, interoperable display solution, enabling designers to lower their risk and cost of integrating the IP into application processors, display bridge integrated circuits (ICs) and multimedia coprocessors.

Key features

  • Compliant with the VESA DSC 1.2a and 1.1 specifications
  • Supports all DSC video formats: RGB, YCbCr, native 4:2:2/4:2:0, simple 4:2:2
  • Supports the latest interface standards: HDMI 2.1, MIPI DSI, DisplayPort
  • Configurable IP delivers low-power and small area
    • Multiple slice decoding: 1, 2, 4, 8, 12, 16
    • Precision: 8, 10, 12, 14, 16 bits
    • Selection of coding schemes (MMAP, BP, MPP, ICH)
  • Single port RAM-based buffers
  • Picture Parameter Set (PPS)
  • Highly programmable with APB-3 based
  • register interface
  • Error reporting for robust auto-recovery

Block Diagram

dwc_vesa_vdcm_1_1_encoder block diagram

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.

Specifications

Identity

Part Number
dwc_vesa_vdcm_1_1_encoder
Vendor
Synopsys, Inc.
Type
Silicon IP

Provider

Synopsys, Inc.
HQ: USA
Synopsys is a leading provider of high-quality, silicon-proven semiconductor IP solutions for SoC designs. The broad Synopsys IP portfolio includes logic libraries, embedded memories, analog IP, wired and wireless interface IP, security IP, embedded processors and subsystems. To accelerate IP integration, software development, and silicon bring-up, Synopsys’ IP Accelerated initiative provides architecture design expertise, pre-verified and customizable IP subsystems, hardening, and signal/power integrity analysis. Synopsys' extensive investment in IP quality, comprehensive technical support and robust IP development methodology enables designers to reduce integration risk and accelerate time-to-market.
