Vendor: intoPIX Category: Video Processing

TicoXS | JPEG XS HD Encoder / Decoder IP-cores

JPEG XS has been co-created by intoPIX.

Overview

JPEG XS has been co-created by intoPIX. TicoXS is an evolution of TICO RDD35 offering more compression capabilities with an extremely small footprint in ASIC and FPGA and fast performances on CPU & GPU.

intoPIX has made significant intellectual property development in lightweight low latency video compression, from inventing and standardizing the world’s smallest and fastest mezzanine compression technology TICO (SMPTE RDD35) supported by the TICO Alliance, to being the proponent and co-developer for creating the world first international ISO standard JPEG-XS technology addressing this matter.

The technology and associated products are covered by one or more claims of patents awarding intoPIX hard work and innovation.

Key features

  • Near-Lossless up to 6:1.
  • Visually lossless up to 12:1
  • Color format : RGB,YUV, YCbCr, 444 / 422 /420 / monochrome
  • Smooth lossy compression beyond
  • Robust over multiple coding
  • Low power / small for FPGA or ASIC. Low logic & low memory usage (no external DDR)
  • Easy to integrate : JPEG-XS Interoperable and Built for many use cases IP-cores and software libraries are licensable from intoPIX
  • Highly parallelizable, Real-time or faster than real-time in CPU and GPU
  • Mobile to 4K/8K : Compatible with different resolutions, via multiple usual transport schemes.
  • Zero latency : few lines of latency : < 1 ms

Benefits

  • SAFEGUARDING ALL ADVANTAGES OF AN UNCOMPRESSED STREAM
    • Low power consumption (through lightweight processing),
    • Ultra low-latency in coding and decoding.
    • Lossless picture quality
    • Small size on chip
    • Fast on software (CPU with the use of SIMD and GPU)
  • WITHOUT SIGNIFICANT INCREASE IN REQUIRED BANDWIDTH & COST
    • Low power consumption (through reasonable bandwidth interfaces)
    • Longer cable runs
    • Perfect fit for existing and new infrastructures
    • More pixels at a reduced cost (more resolutions, higher frame rates, higher bit depth)

Applications

  • Latency critical AV over IP, KVM, Video Wall management
  • Studio over IP, Live Production, Editing , SMPTE 2110
  • Move to IP and SMPTE 2110 workflows
  • Display Connectivity & Interfaces and Mobile Devices
  • Image Sensors & Cameras (HD,4K,8K,360, High Speed)
  • Cable Extenders
  • Wireless / Wired Connectivity
  • Automotive, ADAS systems
  • Machine Vision (cameras, frame grabber, extenders)
  • Medical , Operating Rooms
  • VR/AR system transmission

What’s Included?

  • Netlist for the intel or Xilinx FPGAfamilies
  • RTL code for ASIC
  • Fast SDK running on Intel/AMD x86-64 CPU
  • Fast SDK running on Nvidia GPU
  • User Guides
  • Simulation model : Reference software

Specifications

Identity

Part Number
IPX-JPEG-XS-HD
Vendor
intoPIX
Type
Silicon IP

Files

Note: some files may require an NDA depending on provider policy.

Provider

intoPIX
HQ: Belgium
intoPIX creates and licenses innovative image processing & compression technology since 2006. The intoPIX IP-cores and SDKs enable to simplify video connectivity, to reduce latency, and reduce power while increasing quality and resolutions in many devices and applications. intoPIX has developed a wide range of IP-cores for ASIC & FPGA including TICO RDD35, JPEG XS, JPEG2000, TICO-RAW, AES, RSA, SDI-MAP as well as accelerated software tools for ARM, x86 CPU or GPU architectures for image processing, compression, and streaming. intoPIX technologies are used in image sensors and cameras, automotive ADAS systems, mobile devices, displays, wireless video, medical applications, AV over IP , aerospace, industrial vision, and any other audio-visual applications where image and video quality is a crucial asset. intoPIX plays an active role in several international standardization committees, including JPEG, MPEG, SMPTE, VSF, MIPI,.. In 2019, intoPIX co-created and standardized the ISO JPEG-XS codec for low complexity low latency compression. Thanks to its widely recognized expertise and international presence, the intoPIX team guarantees top-notch quality for every customer, both in terms of product and support. Since 2006, intoPIX creates and licenses innovative technology for low power, low complexity image processing, video compression, and encryption. The intoPIX IP-cores and SDKs enable to simplify video connectivity, to reduce latency, and reduce power while increasing quality and resolutions in many devices and applications. intoPIX has developed a wide range of IP-cores for ASIC & FPGA including TICO RDD35, JPEG-XS, JPEG2000, TICO-RAW, AES, RSA, SDI-MAP as well as accelerated software tools for CPU or GPU architectures. intoPIX technologies are used in image sensors and cameras, automotive ADAS systems, mobile devices, displays, wireless video, medical applications, AV over IP, aerospace, industrial vision, and any other audio-visual applications where image and video quality is a crucial asset. intoPIX plays an active role in several international standardization committees, including JPEG, MPEG, SMPTE, VSF, MIPI,.. In 2019, intoPIX co-created and standardized the ISO JPEG-XS codec for low complexity low latency compression. Thanks to its widely recognized expertise and international presence, the intoPIX team guarantees top-notch quality for every customer, both in terms of product and support.
