MIL1553B IP Core

MIL-STD-1553B is a military specification for a Digital Time Division Command/Response Data Bus, featuring half-duplex, Mancheste…

Contact Provider Request Datasheet

Overview

MIL-STD-1553B is a military specification for a Digital Time Division Command/Response Data Bus, featuring half-duplex, Manchester II encoding. A main bus controller (BC) manages communication, while remote terminals (RTs) respond. It defines terminal operations, word structure, messaging protocol, and electrical characteristics.

Key features

  • High bit error reliability
  • Dual redundancy : Two buses supported
  • BC, RT and BM Modes are supported.
  • Manchester II encoding
  • Parity & Gap generators & checkers for high data integrity
  • AXI4 Compatibility for user interface
  • IP portable to any available standard FPGA
  • 1 Megabit per sec (Mbps) transfer rate

Block Diagram

MIL1553B IP Core block diagram

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.

Specifications

Identity

Part Number
MIL1553B IP Core
Vendor
Logic Fruit Technologies
Type
Silicon IP

Provider

Logic Fruit Technologies
HQ: India
Logic Fruit Technologies designs and deploys embedded solutions for customers around the world. The company has specific experience FPGA Design Services, Hardware Design Services, RTL Testing, variety of Digital Protocols, Communication Buses and Tools, including 1G, 10G Ethernet, PCIe, DIGRF, USB3.0, STM, HDMI, and software-defined radio (SDR), as well as Encryption, Protocol Compliance, Signal Generation, Data Analysis, IoT Technology, and Multiple Image Processing Techniques.
