Vendor: Synopsys, Inc. Category: eFuse / OTP

GF 22FDX 5.5V OTP Auto-Grade1 IO Inline

Designers face the challenge of creating secure, cost-effective, low power, and reliable SoC designs.

Contact Provider Request Datasheet
GlobalFoundries 22nm FDX View all specifications

Overview

Designers face the challenge of creating secure, cost-effective, low power, and reliable SoC designs. Synopsys’ embedded one-time programmable (OTP) non-volatile memory (NVM) IP, based on XHF architecture, enables designers to address these challenges. Synopsys’ OTP NVM IP architecture provides high levels of security, high yields, low power, and excellent reliability, which is why Synopsys OTP NVM is the leader in antifuse technology with >10B units shipped and availability in more than a dozen foundries.

Synopsys OTP NVM IP is silicon-verified in TSMC N4P, N5, N5A, N6, and N7. Synopsys OTP in TSMC N5A is Grade-1 qualified to AEC-Q100 standard

Synopsys OTP NVM offers non-volatile storage for configuration, trimming, calibration, and encryption keys with the Base Capacity OTP product (XBC OTP), code storage with the High-Capacity OTP product (XHC OTP), and secure storage with the Secure Code OTP product (XSC OTP).

Synopsys OTP XBC IP is Automotive Grade 1 AEC-Q100 Qualified and is delivered with ISO 26262 functional safety deliverables for random hardware faults, reducing risk, accelerating AEC-Q100 product-level qualification, and meeting the stringent quality requirements for automotive SoCs.

Available in standard CMOS processes, Synopsys OTP IP does not require any additional mask layers or process steps and provides an alternative to mask ROM, eFuse and embedded Flash memory.

Synopsys OTP NVM IP addresses the power, form factor and security requirements of a broad range of applications, including code storage, encryption keys, analog trimming, and IC configuration in Power Management ICs (PMICs), Sensors, Home Entertainment, Automotive, Industrial, Mobile, Mil/Aero and IoT products.

Key features

  • Anti-fuse OTP ensure security, scalability, and reliability
  • Automotive AEC-Q100 Grade-1 qualified and with ISO 26262 functional safety deliverables for random hardware faults
  • Optimized for area, programming time, and power
  • High level of security prohibits memory content modification
  • Flexible, field-programmable memory
  • Built-in error correction schemes available
  • Comprehensive manufacturing built-in test features available

Block Diagram

dwc_io_gf22fdx_5p5v_otp_i_ag1 block diagram
