The APB Channel provides the necessary infrastructure to connect as many as 16 AHB Slaves (numbered 0-15) to an APB Bus Master.
Overview
The APB Channel provides the necessary infrastructure to connect as many as 16 AHB Slaves (numbered 0-15) to an APB Bus Master. The APB Channel performs a combinational decode on the incoming APB address to produce the block selects for the various APB Slaves.
Typically, the APB Channel is connected as in the following description. Each of the APB Channel’s 16 Mirrored Slave Ports is connected to an APB Slave module (e.g. Timer, UART, GPIO). On the Master side, the APB Channel’s Mirrored Master Port typically is connected to an AHB to APB Bridge module.
Key features
- AMBA® APB 2.0 and 3.0 Compatible
- Bus Infrastructure for up to 16 APB Slaves
- Includes address decode
- Includes read data muxing
Block Diagram
APB Channel with Decoder and Data Mux block diagram
What’s Included?
- Verilog Source
- Complete Test Environment
- AHB Bus Functional Model
- C Sample Code
Files
Note: some files may require an NDA depending on provider policy.
Specifications
Identity
Part Number
APB Channel with Decoder and Data Mux
