RTC Verification IP

The RTC verification IP provides an effective and efficient way to verify the components (data converters and/or logic devices) connecting with RTC link. The RTC VIP is fully compliant with DS3234 maxim_spi_rtc. This VIP is lightweight VIP with an easy plug-and-play interface so that there is no hit on the design time.

• Compliant to RTC basic specification as defined in DS3234 maxim_spi_rtc
• Supports configurable timing parameters and multi-slave configurations.
• Supports multi-slave memory.
• Supports Master and Slave Mode.
• Supports data width of 8 bits.
• Supports baud rate selection.
• Supports internal clock division checks.
• Supports single and burst transfer mode
• Supports on-the-fly generation of data.
• Provides full control to the user to enable/disable various types of messages.
• Integrates easily in any verification environment.
• Supports full-timing models or bus functional models.
• Supports advanced System Verilog features like constrained random testing.
• Supports Callback/ User Configuration in all components.
• Supports ECC.
• Support Mode 0 (CPOL=0) and Mode 3 (CPOL=1)
• Supports SDR, DDR, DUAL, DUAL I/O, DDRDUAL I/O, QUAD, QUAD I/O ,DDRQUAD I/O modes.
• Has assertion and coverage with more than 95% functional coverage.
• Has constraint random testcases to assure the specification is thoroughly met.
• Supports all possible frequencies mentioned in the specification.
• Supports optional data masking feature.
• Supports 1s-1s-1s and 8D-8D-8D mode and dynamic mode between them.
• Supports a wide variety of Dynamic as well as Static Error Injection scenarios

• Available in native System Verilog (UVM/OVM/VMM) and Verilog
• Unique development methodology to ensure the highest levels of quality
• Availability of Compliance & Regression Test Suites
• 24X5 customer support
• Unique and customizable licensing models
• Exhaustive set of assertions and coverage points with connectivity examples for all the components
• Consistency of interface, installation, operation, and documentation across all our VIPs
• Provide complete solutions and easy integration in IP and SoC environment

• RTC slave flash memory Model
• RTC Monitor & Scoreboard
• RTC MASTER BFM/Agent
• Test-Bench Configurations
• Test Suite (Available in Source code)
  • Basic Protocol Tests
  • Directed & Random Tests
  • Assertions & Cover Point Tests
• Integration Guide, User Manual, and Release Notes
