GDDR6 Verification IP

The GDDR6 Verification IP provides an effective & efficient way to verify the components interface with the GDDR6 interface of an ASIC/FPGA or SoC. The GDDR6 VIP is fully compliant with Standard GDDR6 Version JESD250B specification from JEDEC. This VIP is a lightweight with an easy plug-and-play interface so that there is no hit on the design time and the simulation time.

• Compliant to JEDEC GDDR6 SDRAM Specification version JESD250B.
• Supports connection to any GDDR6 Memory Controller IP communicating with a JESD250B compliant GDDR6 Memory Model.
• Supports configurable SDRAM addressing of different sizes (x8 and x16).
• Available in all memory sizes from 4 Gb to 16 Gb per channel.
• Supports multi-channel.
• Supports Double and Quad data rates for WCK
• Support Pseudo Channel mode operation.
• WRITE Data mask function via CA bus (single/double-byte mask).
• Supports Data bus inversion (DBI).
• Supports Command Address bus inversion (CABI).
• Supports all types of training.
• Supports Data Mask function.
• Supports configurable timing parameters and rank associations.
• Supports capturing all the valid GDDR6 commands including Activate, Read Write, Pre-charge.
• Supports Power-up Reset and initialization sequences.
• Supports Power-Down, Self-Refresh & Hibernate Self-Refresh operation.
• Supports RDQS mode.
• Supports EDC for both write and read operations.
• Supports EDC half and full rate.
• Supports Dynamic Voltage Switching.
• Supports Temperature sensor.
• Supports clock to stop, frequency change, and duty cycle corrector.
• Supports all mode registers configurations.
• Supports Multi Environment.
• Reports various timing errors, which can be used to check any timing violations.
• It provides full control to the user to enable/disable various types of messages.
• Supports full-timing models or bus functional models.
• Supports advanced System Verilog features like constrained random testing.
• Strong Protocol Monitor with real-time exhaustive programmable checks.
• Supports Dynamic as well as Static Error Injection scenarios.
• On the fly protocol checking using protocol check functions, static and dynamic assertion.
• Built-in Coverage analysis.
• Provides a comprehensive user API (callbacks) in Monitor, Controller, and Memory Model BFMs.
• Graphical analyzer to show transactions for easy debugging.

• Available in native SystemVerilog (UVM/OVM/VMM) and Verilog
• Unique development methodology to ensure the highest levels of quality
• Availability of various Regression Test Suites
• 24X5 customer support
• Unique and customizable licensing models
• Exhaustive set of assertions and cover points with connectivity example for all the components
• Consistency of interface, installation, operation, and documentation across all our VIPs
• Provide complete solution and easy integration in IP and SoC environment

• GDDR6 SDRAM Model
• GDDR6 Monitor & Scoreboard
• GDDR6 Memory Controller BFM/Agent
• GDDR6 PHY
• Test-Bench Configurations
• Test Suite (Available in Source code)
  • Basic Protocol Tests
  • Assertions & Cover Point Tests
• Integration Guide, User Manual, and Release Notes
