Cascoded GaN high voltage driver

STAR2040 is a CMOS cascode driver circuit designed for use with high-current GaN (or SiC) power FET devices.

Contact Provider Request Datasheet

Overview

STAR2040 is a CMOS cascode driver circuit designed for use with high-current GaN (or SiC) power FET devices. It can be operated with 20 A of current, with a typical on-resistance of <15 milliohms. In a typical usage scenario, the driver can achieve a switching frequency as high as 2 MHz. This permits the use of small external passive components in switching converter applications, and hence a low BOM. The driver is implemented in a standard 5-V CMOS process, without the need for any special high-voltage devices. It requires a single 5-V power supply (VDD).

The driver state is controlled by a differential pair (INP and INM) of 5-V CMOS logic signals; this signalling scheme provides rejection of common-mode noise. Due to the on-chip pre-driver, the drive-current requirement for the INP and INM pins is small. STAR2040 incorporates a variety of monitoring and safety features, such as: (1) an integrated protection diode for the drain node; (2) an integrated analog temperature sensor; (3) a tunable rise/fall-time control circuit; and (4) monitoring capability for the drain, gate, and source nodes. Because of its high current capability, low on-resistance, and high switching frequency, STAR2040 is ideally suited for high-current, high-voltage switching converter applications that require the use of GaN (or SiC) devices. This potentially includes applications such as electric vehicles, high-current appliances, and power supplies for laptop computers.

Key features

  • Current handling: up to 20 A
  • Typical on-resistance: <15 milliohms (@ 20 A)
  • 2-MHz switching capability
    • Permits use of smaller external components
  • Implemented using commodity 5-V CMOS process
    • No high-voltage process required
  • Single 5-V power supply required
    • Current draw: 1.2 A peak, 24 mA average (for 2-MHz switching)
  • 5-V CMOS logic levels used for input control signals
    • Differential signalling used (for better common-mode rejection in noisy environments)
    • Typical input current < 1.5 mA peak (for 4-ns rise/fall time)
    • Output rise/fall time is insensitive to input rise/fall time
  • Additional features: – Built-in protection diode keeps drain node safe – Built-in analog temperature sensor – Rise/fall-time control at gate (set by optional external resistor) – Analog monitoring of drain, gate, source nodes
  • Die size: 4.05 mm x 4.05 mm – Drain connections designed for vertical packaging with GaN device – Source connections can be made with TSVs, for completely vertical current flow

Block Diagram

STAR2040 block diagram

Applications

  • High-current, high-voltage dc-dc converters
    • Electric vehicles
  • High-current ac-dc converters
    • High-current appliances
    • Power supplies for laptop computers

What’s Included?

  • .gds layout database
  • .lib liberty timing models
  • .lef layout exchange format files
  • Extensive documentation
  • Customer support/integration package
  • Design usage training
  • Schematics available
  • Secured online portal

Specifications

Identity

Part Number
STAR2040
Vendor
StarIC Inc
Type
Silicon IP

Files

Product Sheet Download

Note: some files may require an NDA depending on provider policy.

Provider

StarIC Inc
HQ: Canada
StarIC enables innovative and high-performance ASIC and system solutions and IP. Based in Toronto, Canada our team is led by industry veterans and highly experienced experts in the field of mixed-signal design. Many have worked together as a team through prior companies for a number of years. In addition to extensive experience managing and running semiconductor companies, all of StarIC’s leadership have strong engineering backgrounds. At StarIC world-class engineering is at the core of our identity.
